Model Features
- More compact than conventional liquid ring pumps
- No belts, no couplings – alleviating problems with wear, alignment and belts
- Standard models have cast iron housing, Stainless Steel impeller & PTFE flap valve
- Other materials of construction available
- Designed for heavy duty applications
- Manufactured to ISO-9001 Standards
- Single Face Mechanical Seal arrangement is standard
Selection & Ordering Data
Model
|
Rated HP
|
CFM
|
RPM
|
Voltage Range
|
Max Amps
|
Seal Water (GPM)
|
Sound level dB(A)
|
Weight (lbs.)
|
Inlet/Outlet
|
| 3AV 95 |
4.0 |
48 |
1750 |
208-230/460 |
12.9/5.9 |
4.0 |
65 |
130 |
1 1/2″
|
